200W Off - line Laser Perforation Equipment High Speed 40m / min - 300m / min
Off-line Laser Perforation Machine Equipment 40m/min—300m/min
Features
Microcomputer intelligent Control system using the German SIMEMS . Allows you to operate more convenient.
Laser generator used from U.S. SYNAD RF RF-excited CO 2 100W laser, long working life, high stability.
The LCD screen display; setting up various work Parameters, the use of more intuitive.
Mechanical corrective devices to ensure the punch edge distance and flatness of panel face.
Shortcut function keys easy to operate , A click-to-get.
Fault Diagnosis Equipment failure, LCD screen directly for easy maintenance.
Rewinding system adopts Japanese YASKAWA YASKAWA VS-606V7 Inverter systems, reliability can be high
Strong emission of waste, Removal of the production of exhaust gas to maintain the production environment with fresh air.
Rolling pressure paper round.
CTP-L200 Parameters
| Max Diameter of Tipping roll | 510mm | |
| Width of Tipping paper: | 48mm—68mm | |
| Speed of Perforation: | 40m/min—300m/min | |
| Diameter of Perforation: | Min 80*80um Max 400*200um | |
| Density of Perforation: | 5--30pcs/cm(adjusted) | |
| Perforation style: | both sides, 1--6rows each side (Adjusted) | |
| Laser Power: | 200W (import) | |
| Air permeability : | 100CU—1500CU | |
| Stability: | ﹤6% | |
| input power supply: | AC220V50Hz | |
| Max output power: | <5KW | |
| Outside size: | 1700*1550*850mm | |
| Working temperature: | 20℃—25℃ | |
| Weight: | 1.1Ton | |
